Series of hoods/housings | HA |
Hood or Housing | Hood |
Electromagnetic compatibility(EMC) | NO |
Material | Zinc Die-Cast |
Color | Gray |
Cable Entry | TOP entry and SIDE entry |
Size | 3A |
Thread size | M20 / PG11 ( SIDE ENTRY ) M20 / PG11 / PG13.5 / M25( TOP ENTRY ) |
Locking Mechanism | 2 Bolts |
Degree of protection: | IP65 |
Hood seal | NBR |
Field of application | Standard Hoods/housings for industrial applications |
Limiting temperature | -40 ... +125 °C |
Surface (hood) | Powder-coated |
RoHS | compliant |
Type | Part number |
H3A-SE ( Side entry ) -2B-M20 ( thread size ) | 19200031640 |
H3A-SE -2B-PG11 | 09200031640 |
H3A-TE ( Top entry ) -2B-M20 ( thread size ) | 19200031440 |
H3A-TE -2B-PG11 | 09200031440 |
H3A-TE -2B-PG13.5 | 09200031441 |
H3A-TE -2B-M25 | 19200031441 |
Origin | China |
Size Of Drawing
TOP ENTRY :
TOP ENTRY :
TOP ENTRY WITH M25 CABLE THREAD :
Main Components
( complete kit of heavy duty connector )
If you are looking for project solution please feel free to contact us.
Our strong technical team looks forward to working with you.
